Draw-out Ground Monitor

Ensure the Safety of Your Team and Mining Equipment

GET IN TOUCH

Take the first step towards powering up your operations, call us at 276-285-3841

Becker has redefined the mining market by developing a new drawout ground monitor. The new C54 drawout Ground Monitor is for low-medium voltage circuits to monitor continuously the grounding circuit to assure ground wire continuity.

The ground wire from cable being monitored must go through C.T. before being terminated to switchgear case or to the opontial inverse parallel Diode Assembly(C3000). Therefore, the line plug and receptacle must be isolated from the ground wire. A flexible ground strap must be connected between the plug housing and switchgear unit en- closure. It must have the same current rang as the ground conductor. For wiring instructions see terminal connections diagram.

Note: The C3000 Diode Assembly is provided for all applications. Whenever the Diode Assembly is reinstalled the Diode Assembly connections and ground connections should be checked against drawings to prevent nuisance tripping.

Benefits

  • Provides safety for miners
  • Protects customer’s equipment underground
  • Maximizes mine production

Features

  • Drawout Monitor
  • No rewiring to replace Monitor
  • Hot Replacement Operation
Ground Monitor

CALL US TODAY

Learn more about our products with our experts

Operation

Power Supply– 120VAC -Derived from a 120/15 VAC contact voltage transformer with a secondary voltage of 15 VAC + 10% over a primary voltage range of 150/80 volts AC.

Ground Loop Resistance Circuit– Monitors the grounding circuit. The Ground Monitor Relay energizes if the combined pilot to ground wire resistance is less than 7.5 ohms and deenergizes if the combined resistance exceeds 50 ohms.(20 ohms pick up for the shearer option).

Ground Monitor Relay– Special relay that cannot be energized by alternating current. If a pilot to ground fault exists, shorting out the diode at the machine, the ground monitor relay will deenergize and trip the power circuit breaker. Ground Wire Sensor– Monitors the level of current flowing through the ground wire. If the ground wire is broken, the Ground Sensor Relay would sense insufficient current flowing through the ground wire and trip the power circuit breaker.
